Cervical facet joint fluoroscopy

This forum made possible through the generous support of SDN members, donors, and sponsors. Thank you.

Wkrdoc

Membership Revoked
Removed
Joined
Oct 21, 2019
Messages
181
Reaction score
109
Do you guys have any tricks for lining up cervical facet joints in the lateral view? I do all my RFA/MBB in the lateral position.

  • Like
Reactions: 1 user

dhcofc

Full Member
10+ Year Member
Joined
Jan 30, 2008
Messages
145
Reaction score
98
It’s all about c-arm (or bed rotation) and c-arm wig-wag to line up the joints. Lots of small trial and error movements to line up. Also, start out eyeballing the patient’s alignment to have a good starting position for the neck.

  • Like
Reactions: 2 users

paindoc007

Full Member
2+ Year Member
Joined
Aug 4, 2017
Messages
514
Reaction score
442
Do you guys have any tricks for lining up cervical facet joints in the lateral view? I do all my RFA/MBB in the lateral position.

Are the posterior walls of the vb not lined? Oblique the c arm back toward you, or plane the bed toward you.. Are the sup/inf end plates not lined up? Wig wag in one direction. If it gets worse, wig wag in the other.

  • Like
Reactions: 2 users

clubdeac

Full Member
10+ Year Member
Joined
Aug 16, 2007
Messages
4,312
Reaction score
1,439
Whey are you doing RFA in lateral?? That's not good


SommeRiver

Membership Revoked
Removed
Account on Hold
2+ Year Member
Joined
Apr 20, 2018
Messages
2,168
Reaction score
1,649
WigWag and oblique/airplane make the procedure far more reliable IMO.

  • Like
Reactions: 1 users

Wkrdoc

Membership Revoked
Removed
Joined
Oct 21, 2019
Messages
181
Reaction score
109
Whey are you doing RFA in lateral?? That's not good

ive actually done them both prone and lateral. One of my attendings did them all lateral in fellowship. He was one of the best practitioners I’ve seen.

please expand


paindoc007

Full Member
2+ Year Member
Joined
Aug 4, 2017
Messages
514
Reaction score
442
ive actually done them both prone and lateral. One of my attendings did them all lateral in fellowship. He was one of the best practitioners I’ve seen.

please expand

he means ideally with standard RFA probes you want to be as parallel to the nerve as possible, which isn’t a lateral approach. Coolief is different, which is what I use. Kits are pricey though.

  • Like
Reactions: 1 user

clubdeac

Full Member
10+ Year Member
Joined
Aug 16, 2007
Messages
4,312
Reaction score
1,439
ive actually done them both prone and lateral. One of my attendings did them all lateral in fellowship. He was one of the best practitioners I’ve seen.

please expand
Yeah if you’re using standard RF and not coolief and you’re coming in perpendicular to the nerve you’re an idiot. Sorry if that’s harsh but it’s true. You’re doing your patients a disservice and you’re fraudulently billing for a procedure that was not actually done

  • Like
Reactions: 1 user

painfree23

Full Member
5+ Year Member
Joined
Jan 26, 2017
Messages
1,338
Reaction score
384
Yeah if you’re using standard RF and not coolief and you’re coming in perpendicular to the nerve you’re an idiot. Sorry if that’s harsh but it’s true. You’re doing your patients a disservice and you’re fraudulently billing for a procedure that was not actually done

Fraud is a bit excessive. You still get a lesion, just not ideal size.

  • Like
Reactions: 1 user

paindoc007

Full Member
2+ Year Member
Joined
Aug 4, 2017
Messages
514
Reaction score
442
They are $850 each..how do you get them paid for or afford the kit?

I work for a hospital, so I just had to convince them when I started that my efficiency would increase, and results would be better/more consistent so in the long run more return customers

  • Like
Reactions: 1 user

DOctorJay

Full Member
15+ Year Member
Joined
May 8, 2004
Messages
3,654
Reaction score
1,210
I know a lot of people are using stryker venom needles, anyone using Nimbus needles consistently for cervical and lumbar RFA?


DOctorJay

Full Member
15+ Year Member
Joined
May 8, 2004
Messages
3,654
Reaction score
1,210
how do you know how much wig/wag

as much as it takes to get the trapezoids to overlap and line up perfectly. i'm surprised at times how much is required with some patients.

  • Like
Reactions: 1 users

SommeRiver

Membership Revoked
Removed
Account on Hold
2+ Year Member
Joined
Apr 20, 2018
Messages
2,168
Reaction score
1,649
how do you know how much wig/wag

You don't.

Just adjust it and take a pic, adjust, etc...

I recommend you place an MBB needle and adjust it to where you think you're perfect, and then try WigWag and adjust it until your XRAY image is perfect at that level. You'll potentially be a few mm off target.


Wkrdoc

Membership Revoked
Removed
Joined
Oct 21, 2019
Messages
181
Reaction score
109
Yeah if you’re using standard RF and not coolief and you’re coming in perpendicular to the nerve you’re an idiot. Sorry if that’s harsh but it’s true. You’re doing your patients a disservice and you’re fraudulently billing for a procedure that was not actually done

I use cooled

  • Like
Reactions: 1 user

painfree23

Full Member
5+ Year Member
Joined
Jan 26, 2017
Messages
1,338
Reaction score
384
You don't.

Just adjust it and take a pic, adjust, etc...

I recommend you place an MBB needle and adjust it to where you think you're perfect, and then try WigWag and adjust it until your XRAY image is perfect at that level. You'll potentially be a few mm off target.
Do you do any caudal tilt?


SommeRiver

Membership Revoked
Removed
Account on Hold
2+ Year Member
Joined
Apr 20, 2018
Messages
2,168
Reaction score
1,649
Do you do any caudal tilt?

Sure. All of this varies from patient to patient.

Another issue for me at one of my clinics is that the hole the face goes into is radiopaque and seriously in the way.

I do cephalad tilt on that table and I'm coming in superiorly on that table.


NOSfan

Full Member
Lifetime Donor
10+ Year Member
Joined
Aug 15, 2007
Messages
1,421
Reaction score
533
Do you guys have any tricks for lining up cervical facet joints in the lateral view? I do all my RFA/MBB in the lateral position.

Patient prone, head to contralateral side with 0-10 degrees of caudad tilt to open up the joint.


  • Like
Reactions: 6 users

painfree23

Full Member
5+ Year Member
Joined
Jan 26, 2017
Messages
1,338
Reaction score
384
Not to steal the thread but quick question about lumbar RFA. Furman has a interesting method but seems time consuming. I’m sure it works great, but I don’t really do it that way. I just line up end plates , start off a pedicle down and go up to the target.

also, He cranially tilts a lot on his L5 DPR, r u doing the same? I know it’s just to line up end plates, but seems like it takes a lot on his model videos. Not taking anything against him at all,just curious how it translates to real world!

  • Like
Reactions: 1 user

Centurion38

Full Member
2+ Year Member
Joined
Aug 28, 2019
Messages
36
Reaction score
52
How about flexion? Any cushion or positioning device for this view?


Sent from my iPhone using Tapatalk

I used to ask them to flex but you really need positioning pillows hard to do with blankets and reg pillows. Seems uncomfortable for patient. Now I just turn head contralateral and caudal tilt II 15 deg or so which accomplishes the same thing as flexion.


NJPAIN

Full Member
10+ Year Member
Joined
Nov 28, 2011
Messages
2,493
Reaction score
1,459
Do you position similarly for MB RFN?? If so, do you find that the head rotation makes getting a true lateral complicated or do you turn the head back to neutral to get a lateral?



Sent from my iPhone using Tapatalk

  • Like
Reactions: 1 user

manowar rules

New Member
15+ Year Member
Joined
May 30, 2006
Messages
128
Reaction score
50
Do you position similarly for MB RFN?? If so, do you find that the head rotation makes getting a true lateral complicated or do you turn the head back to neutral to get a lateral


Sent from my iPhone using Tapatalk

I’d like to bump this question. I still find cervical RF to be one of the trickiest procedures I do. All is well and good if you have slender necks, but so many of my patients have short fat necks, and/or really old arthritic necks that make rotation problematic. I still go back and forth between lateral and prone positioning. Lateral (still with oblique needle placement) is great until shadow blocks C5 and below. Prone is easier to keep the patient from moving and you can see lower, but I’ve had to use 15cm needles to get anterior enough (had one such fluffy patient today), and I find it tougher to get the needles looking good in my lateral pics. I think I’m pretty good procedurally, but a couple years out and I’m still trying to fine tune these cervicals.

  • Like
Reactions: 1 user

soccrwz

Full Member
10+ Year Member
Joined
Oct 12, 2007
Messages
366
Reaction score
162
  • Like
Reactions: 1 user

lonelobo

PAIN DOC
Removed
15+ Year Member
Joined
Jun 1, 2005
Messages
3,861
Reaction score
1,191
Oak works is an absolute game changer, really consider getting one of these
Yep have used one for last 10 years, can't imagine doing Cervical procedures without


painfree23

Full Member
5+ Year Member
Joined
Jan 26, 2017
Messages
1,338
Reaction score
384

lonelobo

PAIN DOC
Removed
15+ Year Member
Joined
Jun 1, 2005
Messages
3,861
Reaction score
1,191
It sits on top of table, head piece is adjustable


soccrwz

Full Member
10+ Year Member
Joined
Oct 12, 2007
Messages
366
Reaction score
162
Its like night and day, and patients appreciate the increased comfort from this, the patients also move less so less adjustments


buckeye2132

Full Member
2+ Year Member
Joined
Oct 1, 2017
Messages
26
Reaction score
10
how do you position the headpeace for the Oakworks? sometimes i feel like the oakworks actually hinders me, but i don't think I am using it correctly


manowar rules

New Member
15+ Year Member
Joined
May 30, 2006
Messages
128
Reaction score
50
Oak works is an absolute game changer, really consider getting one of these
Thanks, I’m going to have to check this out. Quick online check says these run about $1300, does that sound right?


DOctorJay

Full Member
15+ Year Member
Joined
May 8, 2004
Messages
3,654
Reaction score
1,210
I use that oakworks as well and keep it in a similar position shown in the photo. helps to have a little bit of flexion in the C spine for the procedures and I like how it keeps the patient from moving around too much for CESIs and cervical RFA.

  • Like
Reactions: 1 user
D

deleted993114

Do you guys have any tricks for lining up cervical facet joints in the lateral view? I do all my RFA/MBB in the lateral position.

Why would you inject steroid in cervical facet joints? It doesn't work.

  • Like
Reactions: 1 users
D

deleted993114

I’d like to bump this question. I still find cervical RF to be one of the trickiest procedures I do. All is well and good if you have slender necks, but so many of my patients have short fat necks, and/or really old arthritic necks that make rotation problematic. I still go back and forth between lateral and prone positioning. Lateral (still with oblique needle placement) is great until shadow blocks C5 and below. Prone is easier to keep the patient from moving and you can see lower, but I’ve had to use 15cm needles to get anterior enough (had one such fluffy patient today), and I find it tougher to get the needles looking good in my lateral pics. I think I’m pretty good procedurally, but a couple years out and I’m still trying to fine tune these cervicals.

You will be "fine tuning" your technique your whole career.

You are right- very fat people with short necks are tough to get C6 and lower with a lateral approach. Just do those folks posterior. You can have an assistant (nurse) pull on the arm to get the shadow of the shoulder out of the way.

  • Like
Reactions: 1 user

manowar rules

New Member
15+ Year Member
Joined
May 30, 2006
Messages
128
Reaction score
50
You will be "fine tuning" your technique your whole career.

You are right- very fat people with short necks are tough to get C6 and lower with a lateral approach. Just do those folks posterior. You can have an assistant (nurse) pull on the arm to get the shadow of the shoulder out of the way.

That’s true, although I still may be using the coarse tuning knob for this one, haha. How do you like to do these procedures? Assuming it’s in the prone position, do you put a bolster under the patient’s chest to aid in cervical flexion? I hear people say have the patient turn their head to the contralateral side, but my patients don’t seem to tolerate that well.

I also think I am going to have to start relying more on Mr. Xanax to help patients relax. I rarely find it necessary for lumbar, but these cervical RFs become pretty laborious when my patients are tense and squirmy.

D

deleted993114

That’s true, although I still may be using the coarse tuning knob for this one, haha. How do you like to do these procedures? Assuming it’s in the prone position, do you put a bolster under the patient’s chest to aid in cervical flexion? I hear people say have the patient turn their head to the contralateral side, but my patients don’t seem to tolerate that well.

I also think I am going to have to start relying more on Mr. Xanax to help patients relax. I rarely find it necessary for lumbar, but these cervical RFs become pretty laborious when my patients are tense and squirmy.

I rarely do a posterior approach- only if someone is quite obese or has sclerotomal pain from a C7 level.

Yes- I have always given a little IV versed for cervical rfs, otherwise it is not well tolerated.

  • Like
Reactions: 1 user
