Top Front End quesiton

[john216]

Advertisement - Members don't see this ad

29.

Could you help me how to solve this?
I can't visualize the image.
Is there any good method to solve top front end questions?



[neoking77]

Hey dude,

It's basically 3 hexagons stacked on top of each other.

From the END view, it's evident that the very TOP hexagon is gonna be the one that's sticking out the most towards us

From the FRONT view, it's evident that the TOP hexagon is gonna be in the middle.

These two combined facts leads us with no other choice but B, which shows that the very Bottom/Centred Hexagon is the one that has bolded lines and is the one that's on TOP.

Hope this helps!



[sylviej]

Hey dude,

It's basically 3 hexagons stacked on top of each other.

From the END view, it's evident that the very TOP hexagon is gonna be the one that's sticking out the most towards us

From the FRONT view, it's evident that the TOP hexagon is gonna be in the middle.

These two combined facts leads us with no other choice but B, which shows that the very Bottom/Centred Hexagon is the one that has bolded lines and is the one that's on TOP.

Hope this helps!

I got this question too. but it's so hard to get the picture in 1 minute!!! I thought it was several triangles stacking up.
